Osseous and articular anatomy

The elbow is one of the most congruent, and constrained synovial joints in the body, providing both intrinsic osseous stability as well as a relatively large range of motion. With the evolution from quadrapedal to bipedal locomotion, enhanced stability of the ulnohumeral articulation has led to the upper limb becoming less adapted for weight-bearing and more adapted for tool use and dexterity. Ultimately, the hominid elbow developed articulations that can tolerate little distortion without losing either stability or motion.³

Distortion of the coronoid, radial and olecranon fossae of the distal humerus are common reasons for stiffness. These fossae accommodate the structures for which they are named at the extremes of elbow motion. Implants, scar tissue, fracture callus, malunion, or ectopic bone can obstruct these fossae and thereby limit motion.⁴ Similarly, malunion of the structures that fit into the fossae can cause stiffness (Fig. 28.1).

Figure 28.1 (A) Ectopic bone or fracture callus about the coronoid or coronoid fossae can limit elbow flexion. (B) Ectopic bone, fracture callus or scar tissue in the olecranon fossa or about the tip of the olecranon process can limit elbow extension along with a tight anterior capsule.

Loss of the anterior translation/angulation of the articular surface of the distal humerus can limit elbow flexion. This translation facilitates elbow flexion by allowing clearance of the coronoid with respect to the humeral diaphysis as well as providing space for the muscles and soft tissues when the elbow flexes.¹

Incongruity of the articular surface (including slight subluxation) is a known contributor to loss of motion via arthrosis in the long term, but can also limit elbow motion acutely. This is particularly true for malunited fractures of the radial head, which can limit forearm rotation and malunited fractures of the capitellum and trochlea, which can limit flexion and extension (Fig. 28.2).^4–6 Malunion of the coronoid leads to subluxation of the ulnohumeral joint, and progressive arthrosis and loss of motion.⁷ Arthrosis is limited after a simple olecranon fracture, perhaps because the fractures typically occur in a relatively non-articular portion between the coronoid and olecranon articular facets.

Figure 28.2 (A,B) Anterior-posterior and lateral films of the elbow showing articular malunion that resulted in elbow stiffness. (C) Intraoperative photo showing intra-articular malunion.

Soft tissue contracture

The aetiology of soft tissue contracture about the elbow is multifactorial and incompletely understood. The elbow has the largest capsular capacity in 70° of flexion and any intra-articular effusion, some believe, will cause the patient to assume this elbow position to decrease pressure and pain.⁸ The capsule responds by thickening, further limiting motion⁹ (Fig. 28.1B).

In animal models, ligament and capsular trauma has been shown to lead to increased levels of transforming growth factor β and increased numbers of myofibroblasts that have intrinsic contractile properties.^10,11 Other changes include increased collagen cross-linking and decreased water content that manifests as thickened and less compliant tissue.¹²

Musculotendinous units can contribute to stiffness by either limiting excursion or adhering to bone. After trauma and immobilization, both the elbow flexor and extensor musculature will co-contract and be less elastic. In rat models, sarcomere shortening was seen after only 1 week of immobilization.¹³ Additionally, direct muscle injury may play a role by starting the inflammatory response cascade with possible upregulation of a growth factor that contributes to ectopic ossification around the elbow.^14,15 Lastly, spasticity of muscles about the elbow can be seen after central nervous system injury. Electromyography (EMG) studies in head injury patients have shown the elbow flexors to be more spastic than the extensors, which might contribute to flexion contracture.^16,17 However, despite all of this research data, the exact pathogenesis remains unclear.

Although contracture of the skin is rarely a problem after closed trauma, it can be a major factor after suffering thermal burns (Fig. 28.3) and may be relevant in congenital aetiologies such as pterygium cubitale where cutaneous webs may create contractures.¹⁸ The elbow is the second most common contracture in burn patients, second only to contractures of the shoulder.¹⁹

Figure 28.3 Skin contracture at the elbow in a burn patient after grafting.

Heterotopic ossification

The formation of pathological bone around the elbow occurs in three forms: heterotopic ossification (HO), myositis ossificans and periarticular calcifications. Many authors refer to all three of these as ‘heterotopic ossification’, but distinguishing between them is useful in understanding their treatment. HO refers to the inappropriate formation of mature lamellar bone in soft tissue. Myositis ossificans is the same as HO histologically, but is found only in inflammatory muscle. Periarticular calcifications are amorphous calcium pyrophosphate collections without trabecular organization that is usually seen in the capsule and collateral ligaments.

The elbow is particularly predisposed to HO, but most HO around the elbow does not contribute appreciably to loss of motion. HO is most commonly associated with direct trauma to the elbow and may correlate with its severity: HO is seen in 3% of simple elbow dislocations and up to 20% of fracture elbow dislocations.^20,21 Additionally, HO is associated with neural axis trauma with formation seen below the level of spinal cord injury, specifically on the side of hemiplegia.²² The greatest risk, however, is seen in patients with concomitant head and elbow trauma with up to 80% developing HO.²³ Thermal injury, organ transplantation, early surgical insult and forced manipulation may also predispose the elbow to HO formation.²⁴

The mechanism of formation of this amorphous bone is believed to involve pluripotent cells that come from the surrounding muscle and differentiate into osteoblasts. Though incompletely understood, trauma and inflammation may start this process. Immature heterotopic bone contains woven bone and mineralized bone surrounded by fibroblasts and skeletal muscle cells.²⁵ Mature heterotopic bone is identical to other lamellar bone but is more metabolically active and does not have a true periosteal layer. This picture is consistent with the hypothesis that myositis ossificans represents fibrous replacement of muscular hematoma, though it has not been reproduced in animal studies.²⁶ Most of the heterotopic bone in the elbow that forms after trauma, severe burns, or central nervous system injury forms between the capsule and muscle.²⁷ Attempts to isolate systemic inductive factors in closed head trauma patients has been unsuccessful to date.^1,15

HO may present with swelling, induration and progressive limitation of motion. Motion is limited and there is a firm endpoint. HO can often be seen on radiographs as early as 2 weeks after the precipitating event (surgery, burn, neurological trauma) and progressively develops and matures for up to 3–6 months.

Classification of heterotopic ossification

HO can be classified by either its anatomical appearance or its functional effect (Fig. 28.4). In our experience, HO is most commonly seen posteromedially in burn patients and sometimes encases the ulnar nerve. HO can, however be seen in all anatomical distributions about the elbow in these patients and in patients with central nervous system injury.

Figure 28.4 Anatomical locations of ectopic ossification.

Hastings and Graham developed a classification based on function and motion. Class I patients have radiographic HO, but no functional limitations. Class II patients have HO that creates some functional limitation but does not cause ankylosis. Class III patients are characterized by ankylosis (Fig. 28.5). Both classification systems have further subclassifications based on the type of motion restriction: flexion–extension (A), pronation–supination (B), or both (C) (Table 28.1).²⁸

Figure 28.5 Radiograph showing complete ankylosis of the elbow with large anterior piece of bone held in the foreground after surgical excision.

Table 28.1 Functional classification of elbow heterotopic ossification

Class I	Radiographic heterotopic ossification without functional limitations
Class II	Radiographic heterotopic ossification with subtotal functional limitations
	IIA: Limited flexion–extension
	IIB: Limited pronation–supination
	IIIC: Limited in both planes
Class III	Radiographic and functional ankylosis
	IIA: Ankylosis in flexion–extension
	IIB: Ankylosis in pronation–supination
	IIIC: Ankylosis in both planes

Viola and Hastings classified proximal radioulnar joint (PRUJ) synostosis on the anatomy and surgical approach needed to remove the bone (Fig. 28.6). Type I includes ossification proximally in the PRUJ; type II extends to the bicipital tuberosity; type III is ossification distal in the PRUJ at the level of the bicipital tuberosity. Type I ossification is subtyped into IA, IB and IC based on the need for an anterior or posterior approach, or radial head excision, respectively.²⁷

Figure 28.6 (A,B) Viola and Hastings classification of proximal radioulnar joint (PRUJ) ectopic ossification.

Patient factors

The results of elbow contracture release seem less predictable in paediatric patients.¹⁸ Maturity, direction, motivation and cooperation with postoperative physical therapy may play a role.

A patient’s intuition or automatic thoughts in response to the pain associated with motion and stretching exercises are an important contributor to elbow stiffness. Patients often feel vulnerable when doing painful stretches after injury or contracture release and those that can adopt the more appropriate mindset of the athletic or healthy stretch seem to do better. It is important to be patient as it can take months to make this transition, and the motion can improve once a patient becomes confident with exercises even if they have been stiff for many months. Entrapment or sensitivity of the ulnar nerve, or injury to a nerve from the initial trauma or surgery can make the exercises even more unpleasant and unsettling and can make painful stretching exercises even more counterintuitive. If a correctable nerve problem – such as ulnar neuropathy exacerbated with flexion exercises – can be identified, operative treatment may be useful (Fig. 28.7).²⁹

Figure 28.7 Adherence of the ulnar nerve to a plate seen during elbow contracture release.

Surgeon factors

Surgeon experience and comfort level with managing complex elbow injuries varies. Ideally, fixation of fractures should allow early range of motion in the first few days following surgery, but patients with relatively tenuous fixation as a consequence of poor bone quality or fracture complexity may benefit from greater protection and longer immobilization. Stiffness is usually more responsive to treatment than loss of fixation or damage to the articular surfaces. Technical skill and judgment influence these aspects of caring for patients with complex elbow injuries.

Morrey anatomical classification³⁰

The most commonly used classification system is Morrey’s separation according to factors outside the joint (extrinsic) and factors inside the joint (intrinsic), or both (mixed) (Table 28.2). This simple and anatomically based system is both inclusive and helpful in determining optimal management.

Table 28.2 Morrey’s anatomical classification of elbow stiffness

Extrinsic factors

Skin, muscle, capsule, ligament, extra-articular malunions and non-unions, and HO are extrinsic contributors to elbow stiffness. Specifically in the case of a non-union (Fig. 28.8), substantial motion may occur through the fracture site, allowing for capsular and ligament contracture of the adjacent articulation.

Figure 28.8 Extra-articular non-union leading to elbow stiffness.

Kay classification³¹

According to the Kay classification of elbow stiffness (Table 28.3), type 1 is soft tissue contracture alone as seen in a burn patient with skin contracture at the antecubital fossa; type 2 combines soft tissue contracture with ossification, but no apparent bony elbow trauma as seen in patients with HO after head injury; type 3 stiff elbows are seen in the setting of a minor articular fracture with resulting soft tissue contracture, which is most commonly seen after a simple radial head fracture; type 4 elbows have displaced intra-articular fractures with soft tissue contracture and ectopic ossification; and type 5 elbows have posttraumatic ossific bars that typically result in ankylosis.

Table 28.3 Kay classification of elbow contracture

Simple versus complex stiff elbows

Jupiter et al distinguished the ‘simple’ stiff elbow as characterized by mild to moderate contracture (<80° arc of motion), with no or minimal prior surgery, no prior nerve transposition, no internal fixation, minimal HO and well preserved bony anatomy from the ‘complex’ stiff elbow, that requires more expertise and has a higher surgical complication rate. Most patients with osteoarthritis, rheumatoid arthritis, and osteochondral defects are simple cases of elbow stiffness.³² (Table 28.4).

Table 28.4 Simple versus complex elbow stiffness
