CHAPTER 21 Injuries to the Triangular Fibrocartilage Complex

In 1981, Palmer and Werner used the term triangular fibrocartilage complex (TFCC) to describe the set of related structures at the distal ulnar aspect of the wrist.¹ The TFCC physically separates the distal radioulnar joint (DRUJ) from the radiocarpal joint. The TFCC must be simultaneously robust and flexible. It must have the strength to transmit 20% of the load of the carpus to the ulna and to stabilize the DRUJ and ulnar carpus in conjunction with the bony architecture of the sigmoid notch. It is must also be supple enough to accommodate the significant, complex motion that occurs during forearm rotation. The motion of the DRUJ is a combination of approximately 150 degrees of rotation and sliding. This occurs because the radius of curvature is 50% larger on the radial side of the DRUJ (15 versus 10 mm) (Fig. 21-1A). The axis of rotation passes through the fovea of the ulnar head, which is a major attachment site for the TFCC.

FIGURE 21-1 A, The articulation between the sigmoid notch of the radius and the ulnar head is viewed end-on (left) and dorsally (right). The arc covered with articular cartilage is greater for the ulnar head than for the sigmoid notch, whereas the radius of curvature is greater for the sigmoid notch. This results in rotational and sliding motions during supination and pronation. B, The triangular fibrocartilage complex (TFCC) consists of the triangular fibrocartilage, meniscal homologue, extensor carpi ulnaris tendon sheath, and dorsal and palmar radioulnar ligaments. L, lunate; P, pisiform; R, radius; S, scaphoid; Tq, triquetrum; U, ulna; UL, ulnolunate ligament; UT, ulnotriquetral ligament.

(A, Modified from Chidgey LK. The distal radioulnar joint: problems and solutions. J Am Acad Orthop Surg. 1995;3:95-109; B, Modified from Trumble TE. Distal radioulnar joint and triangular fibrocartilage complex. In: Trumble TE, ed. Principles of Hand Surgery and Therapy. Pennsylvania, PA: WB Saunders; 1999:128.)

The five structures that comprise the TFCC are the articular disk, the distal radioulnar ligaments (palmar and dorsal), the meniscal homologue, and the extensor carpi ulnaris (ECU) sub sheath, which is confluent with the (ulnocarpal collateral ligament (see Fig. 21-1B).² The central portion of the complex consists of an articular disk called the triangular fibrocartilage (TFC). The disk is composed predominately of type II collagen, which is consistent with its role in distributing compressive forces. It lies in the axial plane and structurally represents an extension of the articular surface of the distal radius. Dorsally and palmarly, the TFC is surrounded by the radioulnar ligaments, which are transverse bands that derive their broad origin from the sigmoid notch of the distal radius and insert on the base of the ulnar styloid. The ulnotriquetral and ulnolunate ligaments form the palmar border of the TFCC, and, although Palmer and Werner did not include them in their original description of the TFCC, they serve an important role in the stability of the ulnar side of the wrist.

The ulnar and dorsal edges of the complex consist of the ECU tendon subsheath and dorsal radial triquetral ligament, respectively. When viewed in the axial plane, these borders form a stout pyramid that attaches the TFCC to the ulnar side of the carpus. Stability of the TFCC is a prerequisite for smooth pronosupination and pain-free load bearing through the articular disk. The vestigial meniscal homologue derives from synovium. Its function is unclear, and it is often absent.

The blood supply of TFCC enters from the periphery (Fig. 21-2). Thiru and colleagues evaluated cadaveric specimens and identified three main branches of the TFCC.³ The ulnar periphery of the TFCC has the richest blood supply and, consequently, the greatest potential for healing. It is fed predominantly via the dorsal and palmar radiocarpal branches of the ulnar artery. Dorsal and palmar branches of the anterior interosseous artery supply the more radial part of the complex.

FIGURE 21-2 The prime intrinsic stabilizer of the distal radioulnar joint is the triangular fibrocartilage (TFC). The TFC complex consists of superficial (green) and deep (blue) radioulnar fibers, the two disk-carpal ligaments (disk-lunate and disk-triquetral), and the central articular disk (white). The articular disk is responsible for transferring load from the medial carpus to the pole of the distal ulna. The vascularized, peripheral radioulnar ligaments (green and blue) are nourished by dorsal and palmar branches of the posterior interosseous artery and are responsible for guiding the radiocarpal unit around the seat of the ulna.

(Modified from Kleinman WB: Stability of the distal radioulna joint: biomechanics, pathophysiology, physical diagnosis, and restoration of function: what we have learned in 25 years. J Hand Surg. 2007;32:1086-1106.)

CLASSIFICATION OF TRIANGULAR FIBROCARTILAGE COMPLEX INJURIES

Palmer’s original classification divides injuries of the TFCC into degenerative and acute tears (Box 21-1).⁴ The classification is anatomically subdivided into radial, central, and ulnar tears. This classification bears consideration, because the vascular anatomy dictates the healing potential and therefore the treatment and prognosis for TFCC tears, similarly to tears of the knee’s meniscus.

Palmer class 1 injuries are acute, traumatic injuries. They are subdivided into four types, based on the site of injury (Fig. 21-3):

Type 1A lesions involve the central avascular portion; the rim is still attached to the radius. This lesion usually is not amenable to direct repair. Arthroscopic treatment is limited to débridement of the central tear to remove any flaps that may impede movement (Fig. 21-4).

Type 1B (ulnar-avulsion) lesions are peripheral tears that occur when the ulnar side of the TFCC complex is avulsed from its capsule; they can be associated with ulnar styloid fractures.

Type 1C (ulnar-distal) injuries involve ruptures along the volar attachment of the TFCC or distal ulnocarpal ligaments; they are variably amenable to repair.

Type 1D (radial-avulsion) injuries are rare injuries with tears from the radial attachment. These represent traumatic avulsions of the TFCC from the attachment at the sigmoid notch, with or without a fracture of the sigmoid notch (Fig. 21-5).

FIGURE 21-3 Four types of class 1 lesions of the triangular fibrocartilage complex. L, lunate; R, radius; T, triquetrum; U, ulna.

(Modified from Palmer AK. Triangular fibrocartilage complex lesions: a classification. J Hand Surg Am. 1989;14:594-606.)

FIGURE 21-4 Arthroscopic treatment of type 1A lesions involving the central avascular portion requires d ébridement of the central tear to remove any flaps that may impede movement. A, Lesion in the central portion of the triangular fibrocartilage complex (TFCC). B, Central tear of the TFCC is débrided using a 2.5-mm arthroscopic shaver. C, Ablation at the edge of the lesion using a small joint radiofrequency probe. D, Smooth surface of the lesion after débridement.

FIGURE 21-5 Arthroscopic image demonstrates an avulsion of the triangular fibrocartilage complex (TFCC) from the sigmoid notch of the distal radius (i.e., type 1D TFCC tear).

Degenerative TFCC lesions (Palmer class 2) all involve the central portion and are staged from A to E, depending on the presence or absence of a TFCC perforation, lunate and ulnar chondromalacia, a lunotriquetral ligament perforation, or degenerative radiocarpal arthritis. These degenerative lesions usually arise from ulnar abutment. Class 2 lesions usually are not amenable to surgical repair and are treated with débridement.

TFCC tears can be further subdivided by their acuteness. The chronicity has prognostic implications, and addressing tears in the acute phase usually provides better results.⁵^–⁷

Acute tears (0 to 3 months): Arthroscopic repair of these injuries results in the recovery of 80% of grip strength and range of motion (ROM) compared with the contralateral side (Fig. 21-6). Trumble and associates showed that there was a significant relief of pain postoperatively. Postoperative ROM averaged 89% ± 9% SD of the contralateral side, and grip strength averaged 85% ± 20% SD of the contralateral side.⁶

Subacute tears (3 to 12 months): These tears are amenable to direct repair of the TFCC, but these patients usually regain less strength and ROM than those with acute injuries.

Chronic tears (>1 year): These tears are reparable, but, presumably because of contraction of the ligaments and degeneration of the torn fibrocartilage margins, outcomes lag behind those for acute or subacute tears. The treatment of chronic injuries frequently requires an ulnar shortening osteotomy, with or without TFCC débridement, to decrease load distribution to the distal ulna.⁷^,⁸

FIGURE 21-6 Arthroscopic repairs of acute triangular fibrocartilage complex tears have resulted in the return of 80% of the grip strength and range of motion of the contralateral uninjured wrist.

(Modified from Trumble TE, Gilbert M, Vedder N. Isolated tears of the triangular fibrocartilage: management by early arthroscopic repair. J Hand Surg Am. 1997; 22:57-65.)

The incidence of asymptomatic TFCC tears increases with age. Wright and coworkers, in a study of 62 wrists from cadavers of individuals whose average age at death was 78 years and found a tear of the TFCC in 33 wrists (11 lesions were central, and 21 were vertical radial).⁹^–¹¹ Mikic observed an age-related correlation with disk perforation in his cadaveric study of 180 wrists from fetuses to the elderly. He found the prevalence of perforations to be zero among patients younger than 20 years; 7.6% among those in the third decade; 18.1% in the fourth decade; 40.0% in the fifth decade; 42.8% in the sixth decade, and 53.1% (26 wrists) among patients older than 60 years.⁹ These degenerative changes correlated with magnetic resonance imaging (MRI) findings from healthy volunteers.¹² This illustrates the necessity of correlating imaging with history and examination findings in these patients.

PATIENT EVALUATION

History, Signs, and Symptoms

Ulnar-sided wrist pain has been referred to as the low back pain of the hand surgeon. The multitude of structures and diagnoses that can contribute to a patient’s symptoms are often subtle and require precise physical examination and correlation with history and imaging. Causes of ulnar-sided wrist pain are listed in Box 21-2.

The typical history for an acute TFCC tear involves a fall on an outstretched hand. The literature is controversial regarding which ligaments are tightest in varying positions of forearm supination or pronation, but acute or delayed complaint of ulnar-sided wrist pain, often radiating dorsally and exacerbated by firm grasp and push-off (wrist extended, getting up from a table) is a characteristic features of the patient’s history. Aching with repetitive supination and pronation tasks is also common. The pain is often characterized as diffuse, deep, and sometimes burning.

Chronic attritional injuries and degenerative changes of the ulnocarpal joint, including the TFCC, result from repetitive overloading. Ulnar deviation of the wrist, along with forearm supination and power grasp, increase the damage from axial loads. Pa tients with acquired ulnar positive variance, discussed in greater detail later, are at higher risk for degenerative changes and recurrent injury from minor trauma.

A clicking sensation may be present with wrist pronation and supination. Patients may also complain of generalized weakness with and without wrist loading. Patients often delay treatment or are misdiagnosed as having a “wrist sprain” that fails to improve.

TFCC tears have been associated with distal radius fractures on imaging and direct arthroscopy. The incidence ranges between 13% and 60%.¹³^–¹⁷ The literature does not clearly indicate, in the absence of frank DRUJ instability, which tears should be fixed and by which methods, in part because it is unclear how many of these tears become symptomatic. It is likely that many of these tears are effectively treated by treatment of the concomitant fracture.¹⁴ Nevertheless, several authors have endorsed the use of arthroscopy in the setting of distal radius fracture fixation to identify and treat concomitant soft tissue injuries. Varitimidis and associates reported that 60% of their patients with distal radius fracture had TFCC tears, half of which were ulnar sided.¹⁷ All TFCC tears underwent débridement; 20% (2 of 12) had arthroscopic repair, and 1 patient required open repair. The arthroscopic group demonstrated improved ROM and Mayo wrist scores, compared with those treated with traditional external fixation. In 2003, Ruch and colleagues demonstrated good or excellent results with acute repair of the TFCC at the time of distal radius operative treatment in 56 patients, with only 2 patients with transient ulnar dorsal sensory irritation, but they lacked a control group.¹⁸

Lindau and coworkers reported that 10 of 11 patients with a documented complete peripheral TFCC tear associated with a distal radius fracture exhibited DRUJ instability at a 1-year follow-up examination, compared with 22% of those with no peripheral tear or only a partial tear.¹⁹ This instability was correlated with worse clinical outcome.

Physical Examination

Patients with acute TFCC injuries frequently present with ulnar-sided wrist swelling that may reverse the normal convex shape of the ulnar wrist border. The soft, ballotable region between the ulnar styloid and the triquetrum can frequently be point tender (Fig. 21-7). Clicking can often be elicited with passive and active circumduction of the wrist. Specialized tests to distinguish TFCC injuries from other ulnar wrist injuries include the TFCC compression test, the ulnar impaction test, and the piano key test. Significant pain from axial loading of the TFCC, in conjunction with ulnar deviation, is a positive compression test. Similarly, pain with the combination of wrist hyperextension and the previous maneuvers indicates a positive ulnar impaction test.²⁰ Comparison of any dorsal-volar plane instability of the DRUJ with the normal contralateral side is the piano key test (Fig. 21-8). This should be performed in neutral position, in supination, and in pronation. The DRUJ typically has the most anteroposterior translation in the neutral position. Volar subluxation of the distal ulna with wrist supination can be appreciated by dimpling of the skin of the dorsal ulnar border (Fig. 21-9). Lunotriquetral ballottement tests ligament stability (Fig. 21-10). Pisotriquetral manipulation should be performed to rule out arthrosis of this joint.
